310 Dyno Cams Racing Camshaft, Welded Lobe: GX200, Racing "Clones", & Predators

Product image 1

310 Dyno Cams Racing Camshaft, Welded Lobe: GX200, Racing "Clones", & Predators

Cams

DynoCams 310 Grind, Comp Release, Welded Lobe, Clone Core

The 310 is a monster camshaft with low lift. This cam has all the duration of DYNO's bigger cams, but with .310" lift, so ratio rockers can be used in OHV modified applications. This cam requires an upgraded spring package, billet rod, and billet flywheel. It has the compression release installed, and the lobes are welded.

*Note: The 224 Predator is slightly higher priced.

GX200
SPECIFICATIONS
Engine: 196cc OHV Clone, 212cc Hemi Predator
Recommended Class: Modified
Target (MAX) RPM: 9000
Spring Pressure (In / Ex): 34-36 lbs
Valve Lash (In/Ex): .003"
Ignition Timing: 34 Deg BTDC

PROFILE
Intake Exhaust
Open: 57.15 BTDC 96.10 BBDC
Close: 95.30 ABDC 57.95 ATDC
Lift: .309" .309"
C/L: 108.0 ATDC 108.0 BTDC
DUR @ 50: 255.00 Deg 259.95 Deg

PRED
SPECIFICATIONS
Engine: 212cc Non-Hemi Predator
Recommended Class: Modified
Target (MAX) RPM: 9000
Spring Pressure (In / Ex): 34-36 lbs
Valve Lash (In/Ex): .003"
Ignition Timing: 34 Deg BTDC

PROFILE
Intake Exhaust
Open: 57.15 BTDC 96.10 BBDC
Close: 95.30 ABDC 57.95 ATDC
Lift: .309" .309"
C/L: 108.0 ATDC 108.0 BTDC
DUR @ 50: 255.00 Deg 259.95 Deg

224 Pred
SPECIFICATIONS
Engine: Harbor Freight Predator 224cc, Tillotson 224cc
Target (MAX) RPM: 9000
Spring Pressure (In / Ex): 34-36 lbs
Valve Lash (In/Ex): .003"
Ignition Timing: 34 Deg BTDC

PROFILE
Intake Exhaust
Open: 57.15 BTDC 96.10 BBDC
Close: 95.30 ABDC 57.95 ATDC
Lift: .309" .309"
C/L: 108.0 ATDC 108.0 BTDC
DUR @ 50: 255.00 Deg 259.95 Deg

Cams

DynoCams 310 Grind, Comp Release, Welded Lobe, Clone Core

The 310 is a monster camshaft with low lift. This cam has all the duration of DYNO's bigger cams, but with .310" lift, so ratio rockers can be used in OHV modified applications. This cam requires an upgraded spring package, billet rod, and billet flywheel. It has the compression release installed, and the lobes are welded.

*Note: The 224 Predator is slightly higher priced.

GX200
SPECIFICATIONS
Engine: 196cc OHV Clone, 212cc Hemi Predator
Recommended Class: Modified
Target (MAX) RPM: 9000
Spring Pressure (In / Ex): 34-36 lbs
Valve Lash (In/Ex): .003"
Ignition Timing: 34 Deg BTDC

PROFILE
Intake Exhaust
Open: 57.15 BTDC 96.10 BBDC
Close: 95.30 ABDC 57.95 ATDC
Lift: .309" .309"
C/L: 108.0 ATDC 108.0 BTDC
DUR @ 50: 255.00 Deg 259.95 Deg

PRED
SPECIFICATIONS
Engine: 212cc Non-Hemi Predator
Recommended Class: Modified
Target (MAX) RPM: 9000
Spring Pressure (In / Ex): 34-36 lbs
Valve Lash (In/Ex): .003"
Ignition Timing: 34 Deg BTDC

PROFILE
Intake Exhaust
Open: 57.15 BTDC 96.10 BBDC
Close: 95.30 ABDC 57.95 ATDC
Lift: .309" .309"
C/L: 108.0 ATDC 108.0 BTDC
DUR @ 50: 255.00 Deg 259.95 Deg

224 Pred
SPECIFICATIONS
Engine: Harbor Freight Predator 224cc, Tillotson 224cc
Target (MAX) RPM: 9000
Spring Pressure (In / Ex): 34-36 lbs
Valve Lash (In/Ex): .003"
Ignition Timing: 34 Deg BTDC

PROFILE
Intake Exhaust
Open: 57.15 BTDC 96.10 BBDC
Close: 95.30 ABDC 57.95 ATDC
Lift: .309" .309"
C/L: 108.0 ATDC 108.0 BTDC
DUR @ 50: 255.00 Deg 259.95 Deg
Select SELECT ENGINE
From $41.12

Original: $117.50

-65%
310 Dyno Cams Racing Camshaft, Welded Lobe: GX200, Racing "Clones", & Predators—

$117.50

$41.12

Description

Cams

DynoCams 310 Grind, Comp Release, Welded Lobe, Clone Core

The 310 is a monster camshaft with low lift. This cam has all the duration of DYNO's bigger cams, but with .310" lift, so ratio rockers can be used in OHV modified applications. This cam requires an upgraded spring package, billet rod, and billet flywheel. It has the compression release installed, and the lobes are welded.

*Note: The 224 Predator is slightly higher priced.

GX200
SPECIFICATIONS
Engine: 196cc OHV Clone, 212cc Hemi Predator
Recommended Class: Modified
Target (MAX) RPM: 9000
Spring Pressure (In / Ex): 34-36 lbs
Valve Lash (In/Ex): .003"
Ignition Timing: 34 Deg BTDC

PROFILE
Intake Exhaust
Open: 57.15 BTDC 96.10 BBDC
Close: 95.30 ABDC 57.95 ATDC
Lift: .309" .309"
C/L: 108.0 ATDC 108.0 BTDC
DUR @ 50: 255.00 Deg 259.95 Deg

PRED
SPECIFICATIONS
Engine: 212cc Non-Hemi Predator
Recommended Class: Modified
Target (MAX) RPM: 9000
Spring Pressure (In / Ex): 34-36 lbs
Valve Lash (In/Ex): .003"
Ignition Timing: 34 Deg BTDC

PROFILE
Intake Exhaust
Open: 57.15 BTDC 96.10 BBDC
Close: 95.30 ABDC 57.95 ATDC
Lift: .309" .309"
C/L: 108.0 ATDC 108.0 BTDC
DUR @ 50: 255.00 Deg 259.95 Deg

224 Pred
SPECIFICATIONS
Engine: Harbor Freight Predator 224cc, Tillotson 224cc
Target (MAX) RPM: 9000
Spring Pressure (In / Ex): 34-36 lbs
Valve Lash (In/Ex): .003"
Ignition Timing: 34 Deg BTDC

PROFILE
Intake Exhaust
Open: 57.15 BTDC 96.10 BBDC
Close: 95.30 ABDC 57.95 ATDC
Lift: .309" .309"
C/L: 108.0 ATDC 108.0 BTDC
DUR @ 50: 255.00 Deg 259.95 Deg

You may also like

-65%NEW
Thumbnail 1

Stock Replacement Camshaft for All 6.5 OHV Clones

$6.14

$2.15

-65%NEW
Thumbnail 1

Camshaft, GX390: Aftermarket Replacement (Chinese)

$38.99

$13.65

-65%NEW
Thumbnail 1

Camshaft; GX240, GX270, 8/9hp OHV; Aftermarket Replacement (Chinese)

$41.99

$14.70

-65%NEW
Thumbnail 1

Camshaft, World Formula

$55.35

$19.37

-65%NEW
Thumbnail 1

BILLET NR Racing Camshaft for GX200, 6.5 OHV, and 212 Predators HEMI - CHOOSE GRIND

$189.00

$66.15

-65%NEW
Thumbnail 1

DYNO335-390 Camshaft GX270, GX390, and 13/15hp OHV

$149.00

$52.15

-65%NEW
Thumbnail 1

DYNO-308-ANIMAL CAM World Formula & Animal

$124.00

$43.40

-65%NEW
Thumbnail 1

DYNO-310-ANIMAL Camshaft World Formula & Animal

$124.00

$43.40

-65%NEW
Thumbnail 1

308 Dyno Cams Racing Camshaft, GX200, 6.5 OHV Clone, & 212/224 Predators MOST POPULAR

$114.50

$40.07

-65%NEW
Thumbnail 1

Dyno Cams P-Open Grind, Welded Lobe, Clone 13 HP GX390 Predator 420

$149.00

$52.15

-65%NEW
Thumbnail 1

Dyno Cams MOD2 Camshaft, GX200, Predator 212 224

$62.00

$21.70

-65%NEW
Thumbnail 1

Camshaft, Dyno Cams Mod 1 | GX200, 6.5 OHV Clone, & 212/224 Predators
